APS-101 Series Autoclave Vertical
Product Details:
- Color Gray
- Material Stainless steel
- Product Type Series Autoclave Vertical
- Application Industrial
- Dimension (L*W*H) 250x450mm Millimeter (mm)
- Type Series Autoclave Vertical
- Sterilizing Temperature 134 Celsius (oC)
- Click to view more
APS-101 Series Autoclave Vertical Price And Quantity
- 80000 INR/Unit
- 1 Unit
APS-101 Series Autoclave Vertical Product Specifications
- Industrial
- 134 Celsius (oC)
- 250x450mm Millimeter (mm)
- Series Autoclave Vertical
- Gray
- Stainless steel
- Series Autoclave Vertical
Product Description
Application Areas
- Autoclave Vertica are most ideal for critical applications requiring assured and reliable total destruction of all living micro-organisms
- Autoclave Vertica is low cost options for general sterilization ideal tool for Laboratories Hospitals Nursing Homes R and D labs etc. Pharmaceutical Food and Beverage Industries and Institution
Specification
- Inner Chamber, constructed from SS304 Grade
- Outer body constructed from SS 304 Grade Or Mild steel duly powder coated
- Bucket / Basket Made of Stainless Steel
- Water Level Indicator
- Lid Closing by Radial Locking System
- Sealing of Lid by Neoprene Rubber Gasket / Joint less silicon gasket
- Lid is fitted with Pressure Gauge Spring Loaded Safety Valve.
- Operating range from 15psi to 20psi pressure
- Sterilizing Temperature up to 134C
- Tested up to 2.5 times of required Pressure
- Fitted with Microprocessor based PID controller with respect to time and temperature
- Voltage 220 Volts AC (50 Hz)
| Model | APS-101-22 | APS-101-40 | APS-101-50 | APS-101-100 | APS-101-152 |
| Inner Dimensions (Dia x Height) | 250x450mm | 300x500mm | 350x550mm | 450x600mm | 550x750mm |
| Inches Conversion | 10 x 18 | 12 x 20 | 14 x 22 | 18 x 24 | 22 x 30 |
| Capacity | 22 ltrs | 40 ltrs | 50 ltrs | 100 ltrs | 152 ltrs |
| Working Load | 2.0 KW | 2.0 KW | 3.0 KW | 4.0 KW | 6.0 KW |
| Gasket | Made of Neoprene Rubber / Joint less silicon gasket | ||||
| Sterilizing pressure | 1.2 kgf / cm (15psi)at 121 degree c | ||||
| Pressure Gauge | 0-2.1 kgf / cm2 (30 psi) | ||||
| Operating pressure | From 15 to 20psi (Adjustable) | ||||
| Inner Pressure Tank | Stainless Steel (SS-304) | ||||
| Top Lid | Mild Steel Plate lined with Stainless Steel from inside / Complete Stainless Steel 304 grade | ||||
| Basket | Stainless Steel 304 grade | ||||
| Lid Tightening | Radial Locking system worked by handle | ||||
| Lid Opening | Paddle lifting device | ||||
| Water Level Indicator | Fitted on the outer chamber | ||||
| Boiler- Hydraulically Tested | Upto +40 psi | ||||
| Accuracy | + 3 psi | ||||
| Safety Device | Spring Loaded Type | ||||
| Water Draining System | Hand Operated Valve | ||||
| Heating BY | ISI Marked Immersion Heaters | ||||
| Steam & Vacuum Release | By Valve | ||||
| Power Supply | 220/230V AC 50/60H | ||||
Optional Accessories
| Present Pressure Operation | Automatic Switch PIEZOSTAT (Pressure Control Switch) |
| Heater Safety | Automatic cut-off Device |
| Pre-set Time Operation | By Mechanical / Digital Timers Analogue 0-60 minutes |
| Temperature Display | By Dial Type / Digital Temperature Indicators with LED display. |
| Temperature Recording | Thermograph with / without digital display - Circular Type |
| Dry Sterilization | Triple wall arrangement |
| PLC control panel | For automatic purging and programmable cycle control |
| LCD graphic display | Steam generation process, auto air-purging phase, sterilization and auto steam-exhaust phase proceed automatically. If any errors are depicted they are displayed on Graphic Screen. |
