APS-102 Series Autoclave Horizontal
Product Details:
- Material Stainless steel
- Color Gray
- Application Industrial
- Product Type Series Autoclave Horizontal
- Type Series Autoclave Horizontal
- Working Pressure 10-20 PSI
- Click to view more
APS-102 Series Autoclave Horizontal Price And Quantity
- 250000 INR/Unit
- 1 Unit
APS-102 Series Autoclave Horizontal Product Specifications
- Series Autoclave Horizontal
- 10-20 PSI
- Gray
- Stainless steel
- Series Autoclave Horizontal
- Industrial
Product Description
Application Areas
- Robust and rigid construction.
- Triple walled Horizontal Autoclaves (for Dry Sterilization Steam Jacket and Separate Boiler) are most ideal for bulk sterilization requiring assured and reliable total destruction of all living micro-organisms.
- Triple walled Horizontal Autoclaves is ideal tool for Laboratories, Hospitals, Nursing Homes, Agricultural R and D labs etc, Pharmaceutical, Food & Beverage Industries and Institutions.
- Suitable for Sterilizing hospital dressings, linen, rubber, plastic goods, surgical instruments, glassware, utensils etc.
- These Autoclaves work on the principle of downward displacement of air which is the most economical method of obtaining b sterilization.
- Triple walled with steam jacket and separate boiler is made up of Heavy gauge S.S. Sheet (304 grade) argon-arc welded.
- Outer body made of total stainless steel 304 grade.
- Whole unit horizontally mounted on a sturdy, gauge Stainless steel tubular stand.
- Lid made of stainless steel tightened by Radial Locking System which cannot be opened when under pressure. The self-locking device b automatically disengages the thread mechanism when the sterilizer is under pressure to preclude any eventuality of accident
- Sealing of Lid by Neoprene Rubber Gasket.
- Sterilization cycle is controlled by single point multi port valve fitted at front top. Pressure gauges are fitted to read jacket & chamber pressure on the top A moisture trap is fitted in the chamber discharge line to absorb the condensate automatically to prevent moistening in the chamber.
- Chamber Insulated by Mineral/Glass Wool to minimize the heat losses and is covered by polished stainless steel sheet.
- Fitted with pressure gauge, safety valve and steam release valve.
- Fitted with plug screen to prevent the discharge line from choking.
- Sterilizing Temperature up to 1340C.
- Sterilizing pressure: 1.2 to 1.5 kg/cm2 (15 psi to 22psi)
- Hydraulically Tested up to 40 psi.
- Fitted with Automatic Vacuum Breaker to break the vacuum in case of formation of vacuum due to steam condensation.
- Fitted with Automatic Low Water Level Cut-off Device for Prevention of Heaters.
- Fitted with Automatic Pressure Control Switch to economize power consumption by reducing frequent opening of the steam release valve. It cuts off the power supply to heaters when the set pressure is achieved and re-energizes the heating elements when pressure falls below the set point.
- Fitted with Dial thermometer to indicate the inner chamber temperature.
- Voltage: 440 volts, 3 phase A. C. Supply
Fully Automatic System With Steam generation process, auto air-purging phase, sterilization and auto steam-exhaust phase proceed automatically.
Specification
| Model | APS-102-1 | APS-102-2 | APS-102-3 | APS-102-4 | APS-102-5 |
| Inner Dimensions (Dia x Depth) mm | 350 x 550 | 400 x 600 | 450 x 650 | 500 x 900 | 600 x 1200 |
| Capacity (liters) | 50 | 75 | 110 | 185 | 39 |
| Working Pressure | 10-20 PSI |
|
|
|
|
| Pressure Gauge Range | 0-30 PSI | ||||
| Gasket | Made of rubber gasket | ||||
| Sterilizing pressure | 1.2 kgf / cm2 (15psi) at 121 degree C | ||||
| Operating pressure | From 15 to 30 PSI | ||||
| Inner Pressure Tank | Stainless Steel (SS-304) | ||||
| Top Lid | Stainless Steel | ||||
| Basket | Stainless Steel | ||||
| Lid Tightening | Radial Locking system worked by handle | ||||
| Lid Quality | Stainless Steel | ||||
| Water Level Indicator | Fitted on the outer chamber | ||||
| Boiler -Hydraulically Tested | Up to +40 | ||||
| Accuracy | + 3 psi | ||||
| Safety Device | Spring Loaded Type | ||||
| Water Draining System | Hand Operated Valve | ||||
| Heating | BY ISI Marked Immersion Heaters | ||||
| Steam & Vacuum Release | By Valve | ||||
| Power Supply | 220 volts, 1 phase A.C. Supply OR 440 volts, 3 phase A.C. Supply | ||||
Optional Accessories:
| Double Door | Complete System with Double door option is also available |
| Temperature Recording | Thermograph with / without digital display Circular Type |
| PLC control panel | For automatic purging of stale air sterilizing hold time for sterilizing period and cycle and with automatic exhaust pressure |
| LCD graphic display | Steam generation process, auto air-purging phase, sterilization and auto steam-exhaust phase proceed automatically. If any errors are depicted they are displayed on Graphic Screen. |
